Description

Specifications :
**Fixed Lens
– Image Sensor : 1/3.2” CMOS
– Max. Resolution : 2880 (H) × 1620 (V)
– Illumination Distance : Up to 30 m (98.43 ft) (IR)
– Illuminator Number : 2 (IR LED)
– Angle Adjustment : 0° to 15°
– Lens Type : Fixed-focal
– Focal Length : 3.6 mm
– Max. Aperture : F2.0
– Field of View : H: 86°; V: 46°; D: 104°

**PT Lens
-Image Sensor : 1/3.2” CMOS
– Max. Resolution : 2880 (H) × 1620 (V)
– Illumination Distance :
Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)
– Illuminator Number : 2 (IR LED); 1 (Warm light)
– Angle Adjustment :
Pan: 0° to 349°
Tilt: –5° to 90°
– Lens Type : Fixed-focal
– Focal Length : 3.6 mm
– Max. Aperture : F2.0
– Field of View : H: 86°; V: 46°; D: 104°

– Human Detection : Yes
– Pet Detection : Yes
– Video Compression : H.265
– Video Bit Rate : H.265: 512 kbps–4096 kbps
– Day/Night : Auto(ICR)/Color/B/W
– WDR : DWDR
– Motion Detection : Yes
– Image Rotation : 0°/180°
– Built-in MIC : Yes, built-in Mic
– Built-in Speaker : Yes, built-in speaker
– Audio Compression : G.711a
– Network Port : RJ-45 (10/100 Base-T)
– Wi-Fi : IEEE 802.11a/b/g/n/ac/ax 2.4–2.4835 GHz, 2.4 G, EIRP≤20 dBm & 5.15–5.25 GHz, 5 G, EIRP≤23 dBm@5150–5250 MHz
– Wi-Fi Pairing : Bluetooth pairing
– Storage : Micro SD card (support max. 256 GB)
– Management Software : DMSS
– Mobile Client :iOS;Android
– Power Supply : 5 VDC
– Power Consumption :
Basic: 2.3 W
Max.: 5.2 W (pulling stream+ IR + PT rotation)
– Casing Material : Plastic

What’s in the box :
1x Installation Position Map
1x Screw Package
1x Bracket
1x QR Code
1x Quick Start Guide
1x Legal and regulation information
1x Power Adapter
1x Power Cord
