Description

Image sensor: F1.6@1/3″ Progressive Scan CMOS
Shutter Speed: Self-adaptive shutter
Lens: 4mm, view angle: 90°(Diagonal), 80° (Horizontal), 43°(Vertical)
Lens Mount: M12
Day & Night: IR-cut filter with auto-switching
DNR: 3D DNR
WDR: Digital WDR

Video Compression; H.264/H.265
Video Bit Rate: Adaptive bit rate.

Max. Resolution: 1920 × 1080
Frame Rate: Max:25fps; Self-Adaptive during network transmission

Smart Alarm: Motion detection, Human Detection, Human Tracking, Big Noise Detection, Auto patrol
Wi-Fi Pairing: AP paring
Protocol: EZVIZ cloud proprietary protocol
Interface Protocol: EZVIZ cloud proprietary protocol

Storage: Micro SD card slot (Max. 512G)
Power: TYPE-C
Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Standard: IEEE802.11b, 802.11g, 802.11n
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: Supports 20MHz
Security: WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate: 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
Output Power(EIRP): 19 dBm
Antenna Gain: 1.9 dBi

Operating Conditions: -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply: DC 5V/2A
Power Consumption: 5W max
IR Range: MAX. 10 meters(32.81ft)
Dimensions: 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions: 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
Bare Weight: 218g(0.48lb)

In the box:
– Camera
– Power Adapter
– Power Cable
– Drill Template
– Mounting Plate
– EZVIZ Screw Kit
– Regulatory Information
– Quick Start Guide
