Description

Specifications :
**Fixed Lens
– Image Sensor : 1/2.8″ CMOS
– Max. Resolution : 2880 (H) × 1620 (V)
– Illumination Distance :
Up to 30 m (98.43 ft) (IR)
Up to 20 m (65.62 ft) (Warm light)
– Illuminator Number : 2 (IR LED); 2 (Warm light)
– Angle Adjustment : -10° to 15°
– Lens Type : Fixed-focal
– Focal Length : 2.8 mm
– Max. Aperture : F1.6
– Field of View : H: 95°; V: 53°; D: 110°

**PT Lens
– Image Sensor 1/2.8″ CMOS
– Max. Resolution 2880 (H) × 1620 (V
– Illumination Distance Up to 50 m (164.04 ft) (IR), Up to 40 m (131.23 ft) (Warm light)
– Illuminator Number 2 (IR LED); 2 (Warm light)
– Angle Adjustment Pan: 0° to 352°; Tilt: 0° to 90°
– Lens Type Fixed-focal
– Focal Length 6 mm
– Max. Aperture F1.6
– Field of View H: H: 49°; V: 26°; D: 57°

– Human Detection Yes
– Vehicle Detection Yes
– Video Compression H.265
– Video Bit Rate H.265: 512 kbps–4096 kbps
– Day/Night Auto(ICR)/Color/B/W
– WDR DWDR
– Motion Detection Yes
– Image Rotation 0°/180°
– Built-in MIC Yes, built-in Mic
– Built-in Speaker Yes, built-in speaker
– Audio Compression G.711a
– Network Port RJ-45 (10/100 Base-T)
– Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472, GHz,2.4G,≤20dBm@2400-2483.5MHz
– Wi-Fi Pairing Bluetooth pairing
– Storage Micro SD card (support max. 256 GB)
– Management Software DMSS
– Mobile Client iOS;Android
– Certifications CE
– Power Supply 12 VDC
– Power Consumption
– Basic: 2.3 W
– Max.: 10 W (pulling stream+ IR + siren and light active deterrence)
– Protection IP66
– Casing Material Plastic

What’s in the box :
1x Installation Position Map
1x Screw Package
1x Bracket
1x QR Code
1x Quick Start Guide
1x Legal and regulation information
1x Power Adapter
1x Power Cord
